Product details

Technical Parameter

Light source（光源）: led 600w integrated lamp bead

Maximum power（最大功率）: 800W

Power supply（电源）: wide voltage input switching power supply 100v-240v 50-60Hz

Color temperature（色温）: 6500k

Bulb life（灯泡寿命）: 50000 hours

Spot angle（光斑角度）: 4-50 °

RDM function（RDM功能）: DMX address code, channel mode and other functions can be changed from the console

Control mode（控制模式）: DMX512, automatic operation, master-slave mode

Channel mode（通道模式）: 35CH

X scan（X轴扫描）: 540 ° horizontally,

Vertical（垂直）: 270 °

CMY independent color mixing system, can call up more colors

CTO system（CTO系统）: 0-100% linear CTO regulation

Color disc（颜色盘）: 7 color chips + pure white light, rainbow effect, arbitrary positioning

Rotating pattern disc（旋转图案盘）: 7 pluggable pattern pieces, pattern rotation, pattern flowing effect

Rotation pattern rotation（旋转模式）: it can be positioned at any angle

Fixed pattern（固定图案）: 9 fixed patterns + white light, jitter water effect

Dynamic Effect Disk（动态效果盘）: An independent effect Disk can achieve the effects of water marks, flame and stars.

Cutting plate（切割板）: 8 separate cutting pieces, can cut out various shapes, the cutting plate can rotate 90

Atomizing mirror（雾化镜）: atomizing diffuser

Dimming（调光）: 0-100% linear dimming

Stroboscopic（频闪）: synchronous pulse stroboscopic, random pulse stroboscopic

Prism disk（棱镜盘） :3 prism, bidirectional rotation effect

Focusing（调焦）: the pattern can be adjusted freely and clearly

Zoom in（放大）: the size of the light spot can be adjusted from 4 degrees to 50 degrees

Display（显示）: 2.8-inch color LCD, Chinese and English display, reversible display Menu Operation
