Product details

Model No.: MH-B280S

Item Name: 280W 10R beam spot wash 3in1 moving head

Input Power: AC100V–240V

Frequency: 50/60HZ

Power Consumption: 420W

Bulb: High Brightness 280W Bulb

Lifespan: 2,000 hours

Color Temperature: 8000k

Color Wheel: 1 color wheel, 13 colors+white

Static Gobo: 14 gobos

Rotation Gobo: 9 gobos

Gobo size diameter: 14.9mm, image diameter :13mm

Beam angle: 2.5-20°

Prism: 8 facet prices + 6 linear prism, frost function

Lens: 6 layers optical lens

Zoom: linear zoom

Focus: electronic focus

Dimmer: 0-100% linear dimmer

Strobe/Shutter: two-pieces plate strobe (0.5-9FPS)

Pan : 540°8 Bit/16Bit

Tilt : 270°8Bit/16Bit

Signal connector: 3 & 5 pins XLR in & out

Channel: 16/24 CH

Control model: DMX512/Auto/Master-slave/Sound

Display: Touch Screen

IP level: IP 20

Housing material: heat-proof plastic + module pressing alloy material

0-100% mechanical dimming, mechanical dimming and free dimming available

Magnetic ballast and AC/DC power supply

Net weight: 15.5kg

Gross Weight: 18.0kg

Carton packing size: 45*43*57cm

Flycase packing : 84.5*42*79cm (2pcs)

Gross weight: 60kg
